| Model | DG6500SEW | |
| Frequency(HZ) | 50HZ | 60HZ |
| Max.output (KW) | 1.8 | 2 |
| Rated output(KW) | 1.5 | 1.8 |
| Rated AC Voltage(V) | 110, 220, 230, 240, 110/220, 220/380, 230/400, 240/415 | |
| Power Factor | 1(single phase) / 0.8(three phase) | |
| DC output | 12V/8.3A | |
| Phase | Single Phase/three phase | |
| Alternator Type | Self-excited, 2-pole, Single/three phase alternator | |
| Starting System | Electric | |
| Noise Level (Dba/7m) | 72-75Dba | |
| Fuel Tank Capacity (L) | 16L | |
| Continues Running Time (hr) | 7.3 | 6.8 |
| Engine Model | HR186FA | |
| Engine Type | single-cylinder, vertical, 4-stroke air-cooled diesel engine | |
| Bore×Stroke (mm) | 86×72 | |
| Fuel Consumption rate | ≤280 | |
| Fuel | 0# or -10# light diesel fuel | |
| Lubrication oil Volume (L) | 1.65L | |
| Combustion System | Direct Injection | |
| Voltmeter | YES | |
| AC Output Socket | 2 | |
| AC Circuit Breaker | YES | |
| Oil warning Light | YES | |
| Oil Alert | YES | |
| DC circuit breaker | optional | |
| Hour Meter | optional | |
| Big wheel | optional | |
| Three Phase Voltage | optional | |
| Current Meter | optional | |
| Remote Control | optional | |
| ATS | optional | |
| Welding | optional | |
| Dimension (L×W×H)(mm) | 950×560×760 | |
| Net Weight (kgs) | 160 | |
| 20FT | 72 | |
